SPECIFICATIONS
- Hardware SpecificationsSwitch housing
Plastic
Interface
Eight RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
QoS Ports
Two high-priority QoS ports, two medium-priority QoS ports, and four low-priority QoS ports
LED Indicator
PWR: Power
Per port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Power supply
Input: 100V-240V AC
Output: 5V DC, 1A
Power Consumption
3.0 watt max.
- System SpecificationsStandard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet
Performance
Data transfer rate (half duplex/full duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps
MAC address table: 4K
Memory buffer: 128 KB
Switching fabric (non-blocking): 16 Gbps
Features
Auto-MDI/MDIX in all ports
Transmission method:
Store-and-forward architecture
Port-based Quality of Service (QoS) support
Jumbo Frame support up to 9 KB
- Physical SpecificationsItem dimensions (WxDxH): 138.1 x 67.6 x 28.6 mm (5.4″ x 2.7″ x 1.1″)
Item weight: 118g (0.26 lb.)
Packing dimensions (WxDxH): 142 x 83 x 92 mm (5.6″ x 3.3″ x 3.6″)
Packing weight: 275g (0.61 lb.)
- Environmental SpecificationsTemperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 10% to 90% (Non-condensing)
- CertificationEMC: CE, EAC, FCC, BSMI Class B
- Package ContentsGigabit switch
Power adapter
Quick Start Guide
