SPECIFICATIONS
| Brand: | Western Digital |
| Product Type: | M.2 2280 NVMe |
| Series: | Blue |
| Capacity: | 500GB |
| Interface: | PCI Express 3.0 x4 (NVMe) |
| Features: | 3D NAND Technology |
| SSD Endurance: | 300 TB |
| Internal Data Rate: | 2400 MBps (read) / 1750 MBps (write) |
| 4KB Random Read: | 300000 IOPS |
| 4KB Random Write: | 240000 IOPS |
| MTBF: | 1,750,000 hours |
| Interfaces: | 1 x PCI Express 3.0 x4 (NVMe) – M.2 Card |
| Compatible Bay: | M.2 2280 |
| Power Consumption: | 20 mW (low power active) ¦ 5 mW (sleep) ¦ 3.5 Watt (maximum) |
| Compliant Standards: | UL, TUV, VCCI, C-Tick, BSMI, FCC, KCC |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 70 °C |
| Min Storage Temperature: | -55 °C |
| Max Storage Temperature: | 85 °C |
| Shock Tolerance (operating): | 1500 g @ 0.5 ms half-sine |
| Vibration Tolerance (operating): | 5 g @ 10-2000 Hz |
| Vibration Tolerance (non-operating): | 4.9 g @ 7-800 Hz |
| Dimensions (WxDxH): | 22x80x2.38mm |
| Warranty: | 5 years |
