SPECIFICATIONS
-
- Display
Panel Size: 43″
Type/ Tech: TFT LCD Module. VA type, DLED backlight
Display Area (mm): 941.184(H) × 529.416(V) (42.5” diagonal)
Native Resolution: 3840 x 2160
Aspect Ratio: 16:9
Colors: 1.07G (8bits + FRC-)
Brightness: 450 nits (typ.)
Contrast Ratio: 1200:1 (typ.), 5000:1 (DCR enabled)
Response Time: 6.5ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hours
Surface Treatment: Anti-Glaire, 3H hardness, Haze 25%
Bezel: 9.9/9.9/9.9/9.9 mm (L/R/T/B)
Orientation: Landscape & Portrait - Platform
Processor: Quad-core ARM Cortex A55
RAM: 4GB
Storage: 32GB - INPUT
HDMI: 2.1×2 (3840×2160 @60Hz, HDMI 1 supports ARC)
RS-232: x 1
WiFi Slot: x 1
- OUTPUT
HDMI: 2.0 x1 ( 3840×2160 @60Hz )
SPDIF: x 1 - LAN
RJ45: x 1
- USB
Type A: 2.0 x 1, 3.0 x 1
Type C: x1 ( (DP1.2, PD 65W, USB2.0, 100M ethernet) - SPEAKERS
10W x2
- Embedded OS
Android 11
- POWER
Voltage: 100-240 VAC +/- 10%
Consumption: 64 W(typ.) < 0.5W(off) - OPERATING CONDITIONS
Temperature (º C): 0 to 40℃
Humidity: 10%-90% RH - Operating Hours
7/24
- DIMENSIONS (W x H x D)
Physical (inch / mm): 37.98 x 21.75 x 2.81 in/964.6 x 552.5 x 71.4mm
Packaging (inch / mm): 41.57 x 26.46 x 6.14 in./1056 x 672 x 156 mm - WEIGHT
Net (lb / kg): 21.83lbs/9.9kg
Gross (lb / kg): 30.53lbs/13.85kg - REGULATIONS
cTUVus, FCC/ICES003, Energy star 8.0, EPEAT, Mexico NOM , Mexico Energy, EMC/CE , CB, EAC, UkrSEPRO, RCM, LBL, Flicker free, Green BOM, RoHS , ErP, REACH, SCIP, WEEE , Annex I, Annex II, TPCH , Packing waste, CA65
- PACKAGE CONTENTS
1. Remote Control with batteries
2. Quick Start Guide
3. Power Cables
4. HDMI cable
5. USB-C cable
6. Wall Mount Screw x 4
7. RS232 adapter
8. Compliance statement
