SPECIFICATIONS
| Brand: | TP-LINK |
| Model: | TL-SG1005P |
| Interface: | 5 10/100/1000Mbps RJ45 Ports / AUTO Negotiation/AUTO MDI/MDIX |
| Network Media: | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Quantity: | Fanless |
| External Power Supply: | External Power Adapter(Output: 48VDC / 1.25A) |
| PoE Ports (RJ45): | Standard: 802.3 af compliant PoE Ports: Port1- Port4 Power Supply: 56W |
| Backbound Bandwidth: | 10Gbps |
| Mac Address Table: | 2K |
| Dimensions (WxDxH): | 100 × 98 × 25 mm |
| Max Power Consumption: | 4.0W(no PD load) /64.4W(with 56W PD load) |
| Max Heat Dissipation: | 13.5BTU/h(no PD load) / 219.9BTU/h(with 56W PD load) |
| Advanced Features: | Compatible With IEEE 802.3af Compliant PDs Priority Function Mac Address Auto-Learning And Auto-Aging EEE802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping |
| Transfer Method: | Store-And-Forward |
| Certification: | FCC, RoHS |
| Package Contents: | TL-SG1005P, Power Adapter, Installation Guide |
| Environment: | Operating Temperature: 0℃~40℃ (32℉~104℉) / Storage Temperature: -40℃~70℃ (-40℉~158℉) / Operating Humidity: 10%~90%RH non-condensing /Storage Humidity: 5%~90%RH non-condensing |
| Warranty: | 3 years |
