SPECIFICATIONS
| P/N | CL-P117-CA14BL-A |
|---|---|
| COMPATIBILITY | Intel： LGA 2066/2011/2011-3/1700/1200/1156/1155/1151/1150 AMD : AM5 / AM4 |
| DIMENSIONS | Standard: 148.6 x 146.6 x 165 mm ( L x W x H) 48mm RAM Compatibility: 148.6 x 146.6 x 188.5 mm ( L x W x H) |
| HEATSINK MATERIAL | Aluminum Fins Copper Heatpipes |
| HEATPIPE | Ø6mm x 7 pcs |
| FAN DIMENSION | 140 x 140 x 25 mm ( L x W x H ) |
| FAN QUANTITY | 2 pcs |
| FAN SPEED | PWM 500 ~ 1400 RPM With L.N.C PWM 300~1100 RPM |
| RATED VOLTAGE | 12V |
| START VOLTAGE | 9V |
| RATED CURRENT | 0.17 A (one fan) |
| POWER INPUT | 2.04 W (one fan ) |
| AIR FLOW | 81.96 CFM (one fan ) With L.N.C 65.03 CFM |
| STATIC PRESSURE | 1.81 mm-H2O (one fan) With L.N.C 1.3 mm-H2O |
| ACOUSTICAL NOISE | 23.9 dB-A With L.N.C 18.5 dB-A |
| LIFE TIME/FAN LIFE TIME | 40,000 hours |
| PIN CONNECT | 2510 – 4Pin |
| COOLING POWER | 250 W |
