SPECIFICATIONS
| Brand: | Samsung |
| Product Type: | V-NAND SSD NVMe M.2 |
| Series: | 970 EVO Plus |
| Interface: | PCIe Gen 3.0 x 4, NVMe 1.3 |
| Capacity: | 500GB |
| Maximum Read Speed: | Up to 3,500 MB/s |
| Maximum Write Speed: | Up to 3,200 MB/s |
| Random Read Speed: | Random Read (4KB, QD32): Up to 480,000 IOPS Random Read, Random Read (4KB, QD1): Up to 19,000 IOPS Random Read |
| Random Write Speed: | Random Write (4KB, QD32): Up to 550,000 IOPS Random Write, Random Write (4KB, QD1): Up to 60,000 IOPS Random Write |
| Controller: | Samsung Phoenix Controller |
| NAND Type: | Samsung V-NAND 3-bit MLC |
| Cache Memory: | Samsung 512MB Low Power DDR4 SDRAM |
| AES Encryption: | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Power consumption: | Average: 5.8 W, Maximum: 8 W (Burst mode) |
| Form Factor: | M.2 (2280) |
| Dimensions (WxDxH): | 80.15 x 22.15 x 2.38 mm |
| Weight: | 8g |
| Warranty: | 5 years |
