SPECIFICATIONS
| Brand: |
Seasonic |
| Model: |
B12BC-850 |
| Type: |
Power Supply |
| Certificate: | 80+ Bronze |
| Cybenetics Efficiency Level: | TBA |
| Cybenetics Noise Level: | TBA |
| Form Factor: | Intel ATX 12 V |
| Fan Size: | 120 mm |
| Fan Control: | Smart and Silent Fan Control |
| Fan Bearing: | Sleeve Bearing |
| Life Expectancy: | 25,000 hours at 40 °C, 15 % – 65 % RH |
| Modularity: | Fixed Cables |
| Cable Type: | Flat Black Cables |
| Operating Temperature: | 0 – 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan: | 100,000 hours |
| AC Input: | Full Range |
| Protection: | OPP, OVP, OCP, SCP |
| Safety and EMC: | cTUVus, TUV, CB, CCC, BSMI, CE, FCC |
| Environmental Compliance: | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Voltage Input: | 100 V – 240 V |
| Current Input: | 10 A Max. |
| Frequency: | 50 Hz – 60 Hz |
| Maximum Power +3.3 V: | 15 A / 100W |
| Maximum Power +5 V: | 15 A / 100W |
| Maximum Power +12 V: | 70 A /840W |
| Maximum Power -12 V: | 0.3 A /3.6W |
| Maximum Power +5 VSB: | 2.5 A /12.5W |
| Dimensions(LxWxH): | 140 x 150 x 86 mm |
| Warranty: | 2 years |
