SPECIFICATIONS
| Brand: |
Be Quiet |
| Model: |
BN303 |
| Type: |
Power Supply |
| Energy Protection Properties: | Overcurrent / Overload / Overvoltage / Overheating / short circuit / Undervoltage |
| Overall Performance: | 700 W |
| AC Input Voltage: | 200-240V |
| AC Input Frequency: | 50 Hz |
| Input Current: | 6 A |
| Power Factor: | 0.95 |
| Power factor correction filter (PFC): | Active |
| Combined Current (+ 3.3V): | 130 W |
| Combined Electricity (+ 12V): | 672 W |
| Combined Current (+ 5V): | 130 W |
| Combined Current (-12V): | 3.6 W |
| Combined Current (+ 5Vsb): | 15 W |
| Max. Output Current (+ 3.3V): | 24 A |
| Max. Output Current (+ 12V1): | 33 A |
| Max Output Current (+ 12V2): | 25 A |
| Max output Current (+ 5V): | 15 A |
| Max. Output Current (-12V): | 0.3 A |
| Max. Output Current (+ 5Vsb): | 3 A |
| Hold Time: | 17 ms |
| Efficiency: | 89% |
| Cable Type: | Semi-Modular |
| Motherboard Connector: | 20 + 4 pin ATX |
| Power Cable Length Motherboard: | 55 cm |
| Number Of PATA Power Connections: | 2 |
| Number Of SATA Power Connectors: | 10 |
| SATA Power Cord Length: | 550.670 mm |
| Number Of PCI Express Power Connectors 6 + 2pin: | 4th |
| PCI Express Power Cord Length: | 50 cm |
| CPU Connector (4 + 4 pin): | YES |
| CPU Power Cable Length: | 60 cm |
| Floppy Drive Power Connection: | 1 |
| Certification: | CE / CB / TUV / RCM / CU |
| Compatible Products: | Intel C6 / C7 |
| Power Supply Unit (PSU) Form Factor: | ATX |
| 80 Plus Certification: | 80 PLUS bronze |
| ATX Version: | 2.51 |
| EPS Version: | 2.92 |
| Storage Type: | Protective cover |
| Product Color: | Black |
| Cooling: | Active |
| Fan Diameter: | 12 cm |
| Noise level (Quiet mode, <30%): | 9.7 dB |
| Noise level (sleep mode, 50%): | 14.1 dB |
| Noise level (full load mode, 100%): | 31.7 dB |
| Dimensions(WxDxH): | 150x140x86mm |
| Weight: | 1.69 kg |
| Warranty: | 2 Years |
