SPECIFICATIONS
| Brand: | MSI |
| Model: | X570-A Pro |
| Type: | ATX |
| BIOS Type: | UEFI AMI |
| BIOS Memory Size: | 256 Mbit |
| ACPI Version: | 6.2 |
| Clear CMOS Jumpers: | Yes |
| System Management BIOS (SMBIOS) Version: | 3.2 |
| Processor Manufacturer: | AMD |
| Processor Socket: | Socket AM4 |
| Compatible Processors: |
2nd Generation AMD Ryzen 3, AMD Ryzen 3 3rd Gen, 2nd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9
|
| Maximum Number Of SMP Processors: | 1 |
| Supported RAM: | DDR4 SDRAM |
| Number Of Memory Slots: | 4 |
| RAM Type: | DIMM |
| Memory Channels: | Dual-channel |
| ECC: | Yes |
| Without ECC: | Yes |
| Supported Memory Speed: | 1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400 MHz |
| RAM Memory Maximum: | 128GB |
| Supported Storage Drive Interfaces: | SATA III |
| RAID Level: | 0.1.10 |
| Maximum Graphics Card Memory: | 2048 MB |
| Parallel Processing Technology: | 2-way CrossFireX |
| Maximum Resolution: | 4096 x 2160 pixels |
| Number Of USB 2.0 Interfaces: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Ports: | 2 |
| SATA III Connectors: | 6th |
| Front Panel Audio Connector: | Yes |
| Front Panel Connector: | Yes |
| ATX Power Plug (24-pin): | Yes |
| CPU Fan Connector: | Yes |
| Number Of Chassis fan Plugs: | 4th |
| Chassis Intrusion Connector: | Yes |
| TPM Connector: | Yes |
| 12 V Power Connection: | Yes |
| Serial port headers | 1 |
| RGB LED Pin Header: | Yes |
| Number Of USB 2.0 Ports: | 2 |
| Number Of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: | 4th |
| USB 3.2 Gen 2 (3.1 Gen 2) Number Of Type A Slots: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Number of Type C Slots: | 1 |
|
Number of Ethernet LAN Connections (RJ-45):
|
1 |
| Number of PS / 2 Connections: | 1 |
| Number of HDMI Connections: | 1 |
| HDMI Version | 1.4 |
| S / PDIF out | Yes |
| Optical Audio Digital Output: | 1 |
| Built-in Ethernet Connection: | Yes |
| Ethernet Interface Type: | Gigabit Ethernet |
| LAN Controller: | Realtek RTL8111H |
| Motherboard Chipset: | AMD X570 |
| Audio Chip: | Realtek ALC1220 |
| Audio Channels: | 7.1 channels |
| PC Health Monitoring: | CPU, fan, temperature |
| Number of Mounting Holes: | 9 |
| Supports Windows Operating Systems: | Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64, Windows 10 x64 |
| PCI-Express x1 (Gen 3.x) Connectors: | 3 |
| PCI-Express x16 Slots: | 2 |
| Number Of M.2 (M) Slots: | 2 |
| Supplied Cables: | SATA |
| Driver Included: | Yes |
| Quick Installation Guide: | Yes |
| Warranty: | 2 year |
