SPECIFICATIONS
| Processor |
AMD Ryzen™ 7 5825U (8C / 16T, 2.0 / 4.5GHz, 4MB L2 / 16MB L3)
|
| Graphics |
Integrated AMD Radeon™ Graphics
|
| Chipset |
AMD SoC Platform
|
| Memory |
8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200
|
| Memory Slots |
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
|
| Max Memory |
Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®
|
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
|
| Storage Slot |
Two M.2 slots • One M.2 2242 PCIe® 3.0 x4 slot • One M.2 2280 PCIe 3.0 x4 slot
|
| Card Reader |
SD Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Audio™
|
| Camera |
FHD 1080p with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 45Wh
|
| Power Adapter |
65W USB-C® Slim (2-pin, Wall-mount)
|
| DESIGN | |
| Display |
15.6″ FHD (1920×1080) IPS 300nits Anti-glare, 45% NTSC
|
| Touchscreen |
None
|
| Keyboard |
Backlit, English (UK)
|
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 70 x 105 mm (2.76 x 4.13 inches)
|
| Case Color |
Mineral Grey
|
| Surface Treatment |
Anodizing Sandblasting
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Dimensions (WxDxH) |
357 x 235 x 18.9 mm (14.1 x 9.25 x 0.74 inches)
|
| Weight |
Starting at 1.7 kg (3.75 lbs)
|
| SOFTWARE | |
| Operating System |
None
|
| Bundled Software |
None
|
| CONNECTIVITY | |
| Ethernet |
100/1000M (RJ-45)
|
| WLAN + Bluetooth |
Wi-Fi® 6, 11ax 2×2 + BT5.1
|
| Standard Ports |
|
| Docking |
Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook 15 G4 ABA
|
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
Touch Style, Integrated in Power Button
|
| Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm
|
| Other Security |
Camera privacy shutter
|
