SPECIFICATIONS
| Brand: |
Fractal Design |
| Model: |
ION Gold |
| Type: |
Power Supply |
| Certificate: | 80+ Gold |
| Watts: | 850W |
| Modular Cables: | Fully Modular |
| Fan Type: | 140 mm LLS bearing Fractal Design Dynamic series fan |
| Maximum Operating Temperature (Full Load): | 40°C, 50°C at 80% load |
| Semi-Passive Operation: | No |
| Capacitors: | Primary side: Japanese 105° main bulk capacitor(s) Secondary side: Taiwanese 105°C electrolytic & solid-state capacitors |
| Life Expectancy: | 100,000 hours |
| PSU Specification Compliance: | ATX12V 2.52; EPS12V 2.92 |
| PSU Color: | Black |
| Cable Type: | Modular 24-pin cable: Black wires in braided sleeve, = Other modular cables: Flat black wires |
| Input Voltage: | 100-240V AC |
| Input Frequency: | 50-60 Hz |
| Input Current: | 10A/5A |
| Protection Features: | Over voltage protection, Under voltage protection, Over-power protection, Short circuit protection, Over current protection, Over temperature protection |
| Standby Efficiency: | ErP 2013 (<0.45W @ 230 VAC, 45mA load on +5Vsb) |
| Sleep State Compliance: | C6/C7 Compatible |
| Approvals & Certifications | CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE |
| ATX 24-pin: | 1 |
| EPS/ATX12V: | 2 |
| PCIe 6+2 pin: | 6 |
| SATA: | 8 |
| Peripheral: | 3 |
| DC Output 3.3V: | 22A |
| DC Output 5V: | 22A |
| DC Output 3.3V and 5V combined: | 120W |
| DC Output 12V: | 70.8A |
| DC Output -12V: | 0.3A |
| DC Output +5Vsb: | 3A |
| Total Power: | 850W |
| Warranty: | 7 years |
