SPECIFICATIONS
| Brand: | EDIMAX |
| Model: | AC1200 |
| Interface: | 1 x RJ-45 10/100 Mbps WAN port / 4 x RJ-45 10/100 Mbps LAN port |
| Button: | Reset / WPS Button |
| LED Indicator: | 5G, 2.4G, WAN, LAN, WPS |
| Antenna: | 4 x antenna (2 x 2.4GHz and 2 x 5GHz) / Fixed Omni Directional Antenna |
| Standards: | 802.11 b/g/n/ac |
| Frequency: | 5GHz and 2.4GHz concurrent dual-band |
| Maximum Data Speed: | 5GHz: 867Mbps / 2.4GHz: 300Mbps |
| Power: | DC 12V, 1.0A |
| Security: | WPA-Personal / WPA2-Personal / WPA-Personal/WPA2-Personal / wireless access control / Support hidden SSID |
| Management: | Management / Remote Management / System Status and Security log / Firmware Upgradable / Smart Setup / No Drivers Required |
| WAN Setting: | Basic Setting / Security Setting / Access Control / WPS |
| Virtual Setting: | Port Range, DMZ, UPnP |
| Security Setting: | URL Filter, MAC Filter, Client, WAN ping |
| Operation Mode: | Wi-Fi Router, Access Point, Extender, WISP |
| DHCP: | DHCP Server, Static IP Address Binding, DHCP Client List |
| Certifications: | CE, RoHS |
| Dimensions: | (W x D x H) 153(W) mm x 106(D) mm x 24(H) mm |
| Weight: | 474g |
| Temperature: | 32 – 104°F (0 – 40°C) |
| Humidity: | 10 – 90% (non-condensing) |
