SPECIFICATIONS
| Product Type | Motherboard – micro ATX |
| Chipset Type | Intel B760 |
| Processor Socket | LGA1700 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | (supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron) |
| Supported RAM | Supported RAM |
| Max Size | 96 GB |
| Technology | DDR5 |
| Bus Clock | 5200 MHz, 5600 MHz, 6800 MHz (O.C.), 7200 MHz (O.C.) |
| Supported RAM Integrity Check | Non-ECC |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0, AMD EXPO technology |
| Audio | Audio |
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC897 |
| Compliant Standards | High Definition Audio |
| LAN | LAN |
| Network Controller | Realtek RTL8111H |
| Network Interfaces | Gigabit Ethernet |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Slots | 1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 2 x PCIe 3.0 x1 1 x M.2 socket (2230 M.2 Key E slot) 1 x M.2 socket (2260/2280 M.2 Key M slot) |
| Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 1 x Hyper M.2 SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2 |
| Interfaces | 1 x PS/2 keyboard / mouse 1 x HDMI 1 x DisplayPort 1 x USB-C 3.2 Gen 1 3 x USB 3.2 Gen 1 2 x USB 2.0 1 x LAN (Gigabit Ethernet) 1 x microphone – mini-jack 1 x audio line-in – mini-jack 1 x audio line-out – mini-jack |
| Internal Interfaces | 1 x SPI – header 1 x audio – header 2 x USB 3.2 Gen 1 – header 3 x USB 2.0 – header 1 x speaker – header |
| Power Connectors | 24-pin main power connector, 8-pin ATX12V connector |
| Features | Features |
| BIOS Type | AMI |
| BIOS Features | UEFI BIOS |
| Hardware Features | 5+1+1 Phase Power Design, ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology, ASRock Auto Driver Installer, ASRock Easy RAID Installer, ASRock Full HD UEFI, ASRock Instant Flash, ASRock My Favorites in UEFI, Intel Adaptive Boost Technology (ABT), Intel Hybrid Technology, Intel Thermal Velocity Boost (TVB), Intel Turbo Boost Max Technology 3.0 |
| Miscellaneous | Miscellaneous |
| Included Accessories | IO shield, 3 x M.2 screws |
| Cables Included | 2 x Serial ATA cable |
| Software Included | ASRock A-Tuning, ASRock XFast LAN |
| Compliant Standards | FCC, ErP Ready, EuP Ready, HDCP 2.3, DisplayPort 1.4 |
| Width | 24.4 cm |
| Depth | 20.1 cm |
